Description
Update Your Existing Wood Fireplace or Open Gas Log Insert
Now there’s a quick and easy way to turn your existing fireplace into an energy efficient heat source. Engineered to keep the heat inside your home (and not up the chimney), the Retrofire insert is designed for installation within existing masonry and factory-built wood burning fireplaces.
Room sealed and vented outside, the direct vent Retrofire eliminates smoke, messy ashes and cold drafts.
Gallery
Features
[row]
[col span=”1/2″ ]
- ValorStat Plus remote
Direct Vent onlyValorStat Remote – Mode details - Heats without electricity
Operates even during a power outage - Standard safety barrier screen
High quality ceramic glass window - Direct vent installation
Installs practically anywhere you want - Insert approved
Install as an Insert fireplace
[/col]
[col span=”1/2″ ]
- Modulating Flame
Fire turns down for steady even heat - Heats without the need for a fan
A quieter fireplace experience - B vent installation
Installs practically anywhere you want - ValorComfort
Limited lifetime warranty program
[/col]
[/row]
Retrofire Fireplace Components
ENGINES
| RF24IDN | Retrofire Direct Vent Engine – NG (Comes with ValorStat Plus Remote) |
| RF24IDP | Retrofire Direct Vent Engine – LP (Comes with ValorStat Plus Remote) |
| RF24XBN | Retrofire B-Vent Engine – NG (Comes with ValorStat Remote) |
| RF24XBP | Retrofire B-Vent Engine – LP (Comes with ValorStat Remote) |
ACCESSORIES
| 555CFK | Circulation Fan Kit |
| 559CLT | Co-linear Terminal – chimney liner termination cap (for use with 556CLA) |
| 559SFK | Square Flashing Kit for 559CLT |
| 658DVK | Direct Vent Sidewall Terminal |
| 715CVI | Cast Iron Surround – Vintage Iron – 29″H x 41″W |
| 741SFB | Contemporary Front – Black |
| 741SVI | Contemporary Front – Vintage Iron |
| 743FVI | FenderFire DoubleDoor Front (includes fret) |
| 744FVI | FenderFire SingleDoor (includes fret) |
| 745CFV | Clearview Front Kit – Vintage Iron |
| 746CTK | 3-Sided Contour Trim Kit – Black – 26.75”H x 36.5”W |
| 746VIK | 3-Sided Contour Trim Kit – Vintage Iron – 26.75”H x 36.5”W |
| 747DTK | 3-Sided Deluxe Trim Kit – Black – 26.75”H x 36.5”W |
| 747VIK | 3-Sided Deluxe Trim Kit – Vintage Iron – 26.75”H x 36.5”W |
| 748CTK | 4-Sided Contour Trim Kit – Black – 30.25”H x 36.5”W |
| 748VIK | 4-Sided Contour Trim Kit – Vintage Iron – 30.25”H x 36.5”W |
| 749DTK | 4-Sided Deluxe Trim Kit – Black – 30.25”H x 36.5”W |
| 749VIK | 4-Sided Deluxe Trim Kit – Vintage Iron – 30.25”H x 36.5”W |
| 750OCP | Oversize Closure Kit – Black |
| 750OVI | Oversize Closure Kit – Vintage Iron |
| 751LTK | Lift Trim Kit (must be used with 752BTK – adds 2” in height) |
| 752BTK | Base Trim Kit (may be combined with 751LTK/750OCP) |
| 758CCB | Clearview Cast Fret |
| 1225VFB | Ventana Fret – Black |
| 1236MAP | Metropolis Andiron – Nickel Plated |
| GV60BRK | 1-Hour Shut Down Handset |
| GV60NTK | Non-Thermostat Handset > |
| RA24AV | Avant-Garde Fender – Vintage Iron |
| RA24CV | Contemporary Fender – Vintage Iron |
| GRA24DS | Draw Barrier Screen |
| RA24FS | Fixed Barrier Screen |
| RA24TB | Traditional Fender – Black |
| RA24ZC | Zero Clearance Kit for use with B-Vent Retrofire |
Fireplace Safety – Use Radiant Heat Safely
Fireplace surfaces, in particular the glass viewing window, are extremely hot during operation and will remain hot for a period of time after the fireplace is turned off. Contact with the hot glass can cause severe burns. Close adult supervision is required if there are young children, or at-risk individuals in the house.
Included with your purchase, a Valor Barrier Screen is recommended at all times. Install an approved aftermarket safety gate to keep toddlers, young children and at-risk individuals a safe distance from the fireplace.
For more important fireplace safety information, please visit our Fireplace Safety page.
Retrofire Product Specifications
Glass Dimensions
The glass dimensions of the Retrofire Series (RF24) measure 21.5″ wide x 11.75″ in height for a total of 252.63 square inches.
Model/Fuel
| Model | Gas Type | Input (BTU/HR) | Output Max | |
|---|---|---|---|---|
| High | Low | |||
| RF24XBN | NG | 20,500 | 12,500 | 13,796 |
| RF24XBP | LPG | 19,000 | 12,500 | 12,787 |
| RF24IDN | NG | 24,000 | 10,500 | 16,224 |
| RF24IDP | LPG | 24,000 | 10,500 | 16,224 |
Dimensions & CAD Drawings
